For Cutting Non-Ferrous Castings

Metal Cutter


The Metal Cutter Series are specially designed to cut risers and feeders of non-ferrous materials such as aluminium, bronze and copper.

Both Models use specially developed and hardened blades to cut through the material without bending or damaging them.

Operation is fast, easy and with the simple click of a button. All models are manually operated machines, but can be adapted for robotic online systems.




ModelLengthWeightCylinder OutputBreakable Thickness
AUC-20571mm 8kg 63kN 18mm x 18mm
SCH-1S365mm 48kg 218kN 35mm X 35mm
SCH-1492mm 43kg 218kN 45mm x 45mm
